2008 Johnford VMC-2000 SHD # 1108

Manufacturer: Johnford Control system: Fanuc Year of manufacture: 2008 Table size: 2,200 x 1,000 mm Max. weight on the table: 4 800 Kg Table center / spindle nose: 450 - 1 250 mm Center height: 1 150 mm movements X axis: 2050 mm Y axis: 1 100 mm Z axis: 800 mm Feed: 1 - 8 000 mm / min Fast (X, Y, Z): 15, 15, 12 m / min Milling head Spindle cone: BT-50 / CAT 50 Spindle speed: 10 - 4,500 rpm Spindle power: 18.5 / 15 kW Tools: 24 (32 optional) Max. diameter: 250 mm Max. length: 400 mm Max. weight: 15 kg Cutting capacity: 320 cm3 / min Drilling: Ø 52 mm Thread: M52 Machine weight: 20 tons Floor area: 5.5 x 5.3 m
